True 3K Super HD at 20 fps
With the advanced OmniVision sensor, 120 dB true WDR & 3D DNR, this IP camera brings industry-leading 3K Super HD at smooth 20 fps (3072 X 1728 pixels).
Up to 91° diagonal FoV for 2.8 MM lens, to cover wide-range areas like foyers, front/back doors or yards, parking lots, warehouses, etc.
EXIR 2.0 Night Vision with External Lighting
ANNKE-designed color night vision tech enables the camera to produce colorful videos over 0.028 lux illumination with the external light sources around the camera.
Equipped with the exceptional EXIR tech & smart IR, the camera delivers up to 100 ft long-range black & white night vision in 0 lux illumination conditions, which are too dark to render color images.
Noise-Cancelling Audio
The built-in noise-cancelling microphone can filter the environment noise automatically, and pick up the voice from up to 20 ft away.
Listen-in Audio: Audio recording enhances the security coverage and the ability to interpret events. Record videos with vivid sound instead of silent footages.
Mute Function: Audio record might be regulated based on your location. If the audio surveillance is not allowed or you don’t want audio record, simply mute it.
IP67 Weatherproof – Extreme Weather Capabilities
IP67 rated, the camera is fully weatherproof & can be immersed in 1 m of water for 30 mins. It continues to operate in extreme temperatures as low as -22 °F (-30 °C). Torrential downpours, heavy winds, freezing snow storms, the camera braves them all.
-22 °F | -30 °C
Cold Rating
Metal & ABS
Rugged Housing
140 °F | 60 °C
Hot Rating
IP67
Water Rating
Small on Prices, Big on Features
PoE or DC Power
Power on the camera via PoE with an NVR/PoE injector, or plug it to an outlet for power supply.
Local Storage
Supports up to 256 GB TF card (not included) for local video storage without monthly cloud fees.
Customized Motion Areas
Customize the specific motion zones, like garage, front door, etc. for much more relevant motion alerts.
Motion Alerts & Remote Access
Receive instant app pushes & email alerts when there are motion events. Control the camera remotely with smart devices.
Specification
| I51DS Camera | |
| Image Sensor1/3" Progressive Scan CMOS | Max resolution3K(3072*1728), 16: 9 picture ratio is more suitable for the most popular display |
| Main Stream50 Hz: 20 fps (3072*1728), 25 fps ( 1920 X 1080, 1280 X 720) | Substream50 Hz: 25 fps (1280 X 720,640 X 480, 640 X 360) |
| 60 Hz: 20 fps (3072*1728), 24 fps (1920 X 1080, 1280 X 720) | 60 Hz: 24 fps (1280 X 720,640 X 480, 640 X 360) |
| Video Bitrate32 Kbps - 6 Mbps | Audio CompressionG.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC |
| Audio Input Built-in Microphone, record with audio | Lens2.8 mm |
| Min. Illumination Color: 0.01 Lux @ (F2.0, AGC ON), B/W: 0 Lux with IR | Angle of View Horizontal FOV 99°, vertical FOV 55°, diagonal FOV 116° |
| Number of Infrared LEDs2 pcs | Night Vision Distance Up to 100 ft/30 m |
| Video Compression Main stream: H.265+/H.265/H.264+/H.264 | Motion detection 2.0Supoort, include Human & Vehicle detection |
| Sub-stream: H.265/H.264/MJPEG | |
| Image EnhancementBLC, HLC, 3D DNR | Wide Dynamic Range120 dB WDR |
| Protocols TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, Bonjour, FTP, SMTP | API Open Network Video Interface |
| Region of Interest (ROI)1 fixed region for main stream | Privacy Mask4 programmable polygon privacy masks |
| General Function Mirror, rotate, password protection, video tampering alarm, remote access | Ethernet1 RJ45 10 M/100 M self-adaptive Ethernet port |
| I51DS General | |
| Housing Metal & Plastic | Color White & Black |
| StorageBuilt-in microSD/SDHC/SDXC Slot, up to 256 GB | Hardware Reset Yes |
| Operating PowerDC 12 V± 25%, max. 5 W; PoE (802.3af), max. 6.5 W | Operating Temperature-22 °F – 140 °F/-30 °C – 60 °C |
| Indoor/Outdoor UseIndoor/Outdoor | Interface ProtectionIP67, TVS 2000 V Lightning Protection, Surge Protection and Voltage Transient Protection |
| Dimension (L X W X H)7.0" X 2.6" X 2.7"/177.6 X 66.2 X 67.8 mm | Weight0.6 lb./270 g |
| What's in the Box (I51DL) | |
| ➀ 1X/4X Security Camera(s)➁ 1X/4X Mounting Screw Bag(s)➂ 1X User Manual➃1X Screw Driver (For dome camera only) | |
| I51DL Camera | |
| Image Sensor1/3" Progressive Scan CMOS | Max resolution3K(3072*1728), 16: 9 picture ratio is more suitable for the most popular display |
| Main Stream50 Hz: 20 fps (3072*1728), 25 fps ( 1920 X 1080, 1280 X 720) | Substream50 Hz: 25 fps (1280 X 720,640 X 480, 640 X 360) |
| 60 Hz: 20 fps (3072*1728), 24 fps ( 1920 X 1080, 1280 X 720) | 60 Hz: 24 fps (1280 X 720,640 X 480, 640 X 360) |
| Video Bitrate32 Kbps - 6 Mbps | Audio CompressionG.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC |
| Video Compression Main stream: H.265+/H.265/H.264+/H.264 | Audio Input Built-in Microphone, record with audio |
| Sub-stream: H.265/H.264/MJPEG | |
| Lens2.8 mm | Min. Illumination Color: 0.01 Lux @ (F2.0, AGC ON), B/W: 0 Lux with IR |
| Angle of View Horizontal FOV 99°, vertical FOV 55°, diagonal FOV 116° | Number of Infrared LEDs2 pcs |
| Night Vision Distance Up to 100 ft/30 m | Motion detection 2.0Supoort, include Human & Vehicle detection |
| Image EnhancementBLC, HLC, 3D DNR | Wide Dynamic Range120 dB WDR |
| Protocols TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, Bonjour, FTP, SMTP | API Open Network Video Interface |
| Region of Interest (ROI)1 fixed region for main stream | Privacy Mask4 programmable polygon privacy masks |
| General Function Mirror, rotate, password protection, video tampering alarm, remote access | Ethernet1 RJ45 10 M/100 M self-adaptive Ethernet port |
| I51DL General | |
| Housing Metal & Plastic | Color White |
| Storage Built-in microSD/SDHC/SDXC Slot, up to 256 GB | Hardware Reset Yes |
| Operating Power DC 12 V± 25%, max. 5 W; PoE (802.3af), max. 6.5 W | Operating Temperature-22 °F – 140 °F/-30 °C – 60 °C |
| Indoor/Outdoor Use Indoor/Outdoor | Weight0.6 lb./270 g |
| Interface ProtectionIP67, TVS 2000 V Lightning Protection, Surge Protection and Voltage Transient Protection | Dimension (L X W X H)Ø 110 × 100.8 mm (Ø 4.3" × 4.0") |
| What's in the Box (I51DN) | |
| ➀ 1X/4X Security Camera(s)➁ 1X/4X Mounting Screw Bag(s)➂ 1X User Manual➃1X Screw Driver (For dome camera only) | |
| I51DN Camera | |
| Image Sensor1/3" Progressive Scan CMOS | IVideo compressionH.265+/H.265/H.264+/H.264 |
| Main Stream Max. Frame Rate50Hz: 20 fps (2592 × 1944), 25 fps (2560 × 1440, 2304 × 1296, 1920 × 1080, 1280 × 720) | Sub-stream Max. Frame Rate50Hz: 25 fps (640 × 480, 640 × 360, 320 × 240) |
| 60Hz: 20 fps (2592 × 1944), 30 fps (2560 × 1440, 2304 × 1296, 1920 × 1080, 1280 × 720) | 60Hz: 30 fps (640 × 480, 640 × 360, 320 × 240) |
| Video Bitrate32 Kbps - 8 Mbps | Audio CompressionG.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC |
| Audio input Bulit-in Microphone | Lens2.8 mm |
| Min. Illumination Color: 0.028 Lux @(F2.0, AGC On) | Angle of View Horizontal FoV 71.5°, Vertical FoV 53°, Diagonal FoV 91° |
| Number of Infrared LEDs2 pcs | Night Vision Distance Up to 100 ft/30 m |
| Wide Dynamic Range120DB WDR | DNR3D DNR |
| ONVIF Support | IR Cut Filter Yes |
| EthernetRJ45 X1 (10 M/100 M) | |
| I51DN General | |
| Housing Metal & Plastic | Color White |
| Storage Built-in microSD/SDHC/SDXC Slot, up to 256 GB | Hardware Reset Yes |
| Operating Power DC 12 V; PoE (802.3af) | Operating Temperature-22 °F – 140 °F/-30 °C – 60 °C |
| Indoor/Outdoor Use Indoor/Outdoor | Interface ProtectionIP67, TVS 2000 V Lightning Protection, Surge Protection and Voltage Transient Protection |
| Dimension (L X W X H)Ø120 × 92.2 mm (4.72" × 3.63") | Weight440 g (1.0 lb.) |
| Video & Audio (NVR) | |
| Video CompressionH.264+/H.264/H.265/H.265+/MPEG4 | IP Video Input8CH PoE |
| Video Output HDMI up to 4K; VGA up to 1080p | Audio Input/Output1/1 RCA |
| Incoming Bandwidth80 M | Max Recording Resolution Up to 8MP (3840 X 2160) |
| Max Playback Resolution Up to 8MP (3840 X 2160) | Max Playback Channel8CH |
| Max Playback Capacity4CH @1080p; 1CH @8MP | |
| Hard Drive (NVR) | |
| HDD1 SATA Interface | HDD Capacity Up to 6 TB Capacity for Each HDD |
| External Interface (NVR) | |
| Network InterfaceRJ45 X1 (10/100/1000 M) | PoE8 Ports (IEEE802.3at / af) |
| USB2X USB 2.0 | |
| NVR General | |
| Operating Power DC 48 V | Working Temperature14 °F — 131 °F/-10 °C — +55 °C |
| Dimensions (W X H X D)12.4” X 9.4” X 1.9”/315 X 240 X 48 mm | Weight (Without Hard Disk)2.2 lbs./1 kg |
| Power Consumption≤10 W (Without HDD and PoE) | |
| PoE: Max 25.5 W for Single Port | |
