Panoramic 180° Ultra-Wide Coverage with Dual-Lens Fusion
Experience next-level surveillance with a seamlessly stitched 180° ultra-wide field of view in a cinematic 20:9 aspect ratio. Dual-lens technology delivers unmatched visibility with zero blind spots, ideal for large areas like backyards, squares, or campus.
Stunning 8MP Clarity with High-Sensitivity BSI Sensors
Powered by dual 1/2.5” large-format BSI sensors and premium 2.8mm@F1.6 lenses, this camera delivers crystal-clear 4096 x 1860 resolution at 20fps. Even when zoomed in, every detail remains sharp and vivid—ideal for identifying faces, license plates, and more.
Sound & Light Alarm for Active Deterrence
Stay in control with dual warning methods—siren and flashing light—that can be triggered automatically through alarm linkage or manually via the mobile app.
Choose from 12 built-in alarm sounds or upload your own custom audio for a truly personalized security response.
Smart Dual-Light Modes for Day & Night Clarity
Adapt to any lighting condition with three light modes: White Light, Infrared (IR), and Smart Dual-Light. With up to 30 meters (98 ft) of illumination range, this camera ensures clear monitoring around the clock.
In Smart mode, the camera uses IR lights to provide a black-and-white image at night to reduce light pollution. When motion—like a person or vehicle—is detected, it automatically switches to white light to deliver a full-color image for enhanced detail. Once the event ends, it seamlessly reverts to IR mode.
Smarter Detection with Motion 2.0 – 99% Accuracy
Powered by advanced Motion 2.0 AI technology, this camera uses deep learning algorithms to accurately distinguish between people, vehicles, and irrelevant movements. Say goodbye to constant false alarms caused by wind, animals, or shadows.
Real-Time Two-Way Audio for Instant Communication
Stay in control with built-in microphone and speaker that enable clear two-way talk anytime, anywhere. Whether you’re checking in on loved ones, greeting guests, or warning unwanted visitors, communicate in real time with just a tap on your phone. Hear what’s happening and speak back instantly—no extra devices needed.
Flexible Storage Options for Continuous Protection
This security camera features a built-in TF card slot, supporting up to 512GB Micro SD for loop recording. For expanded storage solutions, the camera also supports NAS and NVR integration, giving you the freedom to choose the storage method that best fits your security setup.
IP67 Weatherproof & Wide Operating Range
Designed for durability, this camera boasts an IP67-rated waterproof and dustproof housing, making it ideal for both indoor and outdoor use—rain or shine. Perfect for large-area surveillance, it’s especially well-suited for plazas, tourist attractions, school campuses, and open public spaces, where a wide-angle view and dependable performance are essential.
Small on Prices, Big on Features
H.265+ Coding
Store more recordings with the same hard drive and enjoy faster video transmission with less bandwidth.
Image Enhancement
With 120dB WDR, BLC, HLC, 3D DNR, you get sharp, balanced footage—even in backlight or glare.
PoE & DC 12V Power Supply
Power on the camera via PoE with an NVR/PoE injector, or plug it into an outlet for the power supply.
APP Control
View current and past situations anytime and anywhere, and support multi-device remote access.
Specification
| I51DS Camera | |
| Image Sensor1/3" Progressive Scan CMOS | Max resolution3K(3072*1728), 16: 9 picture ratio is more suitable for the most popular display |
| Main Stream50 Hz: 20 fps (3072*1728), 25 fps ( 1920 X 1080, 1280 X 720) | Substream50 Hz: 25 fps (1280 X 720,640 X 480, 640 X 360) |
| 60 Hz: 20 fps (3072*1728), 24 fps ( 1920 X 1080, 1280 X 720) | 60 Hz: 24 fps (1280 X 720,640 X 480, 640 X 360) |
| Video Bitrate32 Kbps - 6 Mbps | Audio CompressionG.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC |
| Audio InputBuilt-in Microphone, record with audio | Lens2.8 mm |
| Min. IlluminationColor: 0.01 Lux @ (F2.0, AGC ON), B/W: 0 Lux with IR | Angle of ViewHorizontal FOV 99°, vertical FOV 55°, diagonal FOV 116° |
| Number of Infrared LEDs2 pcs | Night Vision DistanceUp to 100 ft/30 m |
| Video CompressionMain stream: H.265+/H.265/H.264+/H.264 | Motion detection 2.0Supoort, include Human & Vehicle detection |
| Sub-stream: H.265/H.264/MJPEG | |
| Image EnhancementBLC, HLC, 3D DNR | Wide Dynamic Range120 dB WDR |
| ProtocolsTCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, Bonjour, FTP, SMTP | APIOpen Network Video Interface |
| Region of Interest (ROI)1 fixed region for main stream | Privacy Mask4 programmable polygon privacy masks |
| General FunctionMirror,rotate,password protection,video tampering alarm, remote access | Ethernet1 RJ45 10 M/100 M self-adaptive Ethernet port |
| I51DS General | |
| HousingMetal & Plastic | ColorWhite & Black |
| StorageBuilt-in microSD/SDHC/SDXC Slot, up to 256 GB | Hardware ResetYes |
| Operating PowerDC 12 V± 25%, max. 5 W; PoE (802.3af), max. 6.5 W | Operating Temperature-22 °F – 140 °F/-30 °C – 60 °C |
| Indoor/Outdoor UseIndoor/Outdoor | Interface ProtectionIP67, TVS 2000 V Lightning Protection, Surge Protection and Voltage Transient Protection |
| Dimension (L X W X H)7.0" X 2.6" X 2.7"/177.6 X 66.2 X 67.8 mm | Weight0.6 lb./270 g |
| What's in the Box (I51DL) | |
| ➀ 1X/4X Security Camera(s)➁ 1X/4X Mounting Screw Bag(s)➂ 1X User Manual➃1X Screw Driver (For dome camera only) | |
| I51DL Camera | |
| Image Sensor1/3" Progressive Scan CMOS | Max resolution3K(3072*1728), 16: 9 picture ratio is more suitable for the most popular display |
| Main Stream50 Hz: 20 fps (3072*1728), 25 fps ( 1920 X 1080, 1280 X 720) | Substream50 Hz: 25 fps (1280 X 720,640 X 480, 640 X 360) |
| 60 Hz: 20 fps (3072*1728), 24 fps ( 1920 X 1080, 1280 X 720) | 60 Hz: 24 fps (1280 X 720,640 X 480, 640 X 360) |
| Video Bitrate32 Kbps - 6 Mbps | Audio CompressionG.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC |
| Video CompressionMain stream: H.265+/H.265/H.264+/H.264 | Audio InputBuilt-in Microphone, record with audio |
| Sub-stream: H.265/H.264/MJPEG | |
| Lens2.8 mm | Min. IlluminationColor: 0.01 Lux @ (F2.0, AGC ON), B/W: 0 Lux with IR |
| Angle of ViewHorizontal FOV 99°, vertical FOV 55°, diagonal FOV 116° | Number of Infrared LEDs2 pcs |
| Night Vision DistanceUp to 100 ft/30 m | Motion detection 2.0Supoort, include Human & Vehicle detection |
| Image EnhancementBLC, HLC, 3D DNR | Wide Dynamic Range120 dB WDR |
| ProtocolsTCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, Bonjour, FTP, SMTP | APIOpen Network Video Interface |
| Region of Interest (ROI)1 fixed region for main stream | Privacy Mask4 programmable polygon privacy masks |
| General FunctionMirror,rotate,password protection,video tampering alarm, remote access | Ethernet1 RJ45 10 M/100 M self-adaptive Ethernet port |
| I51DL General | |
| HousingMetal & Plastic | ColorWhite |
| StorageBuilt-in microSD/SDHC/SDXC Slot, up to 256 GB | Hardware ResetYes |
| Operating PowerDC 12 V± 25%, max. 5 W; PoE (802.3af), max. 6.5 W | Operating Temperature-22 °F – 140 °F/-30 °C – 60 °C |
| Indoor/Outdoor UseIndoor/Outdoor | Weight0.6 lb./270 g |
| Interface ProtectionIP67, TVS 2000 V Lightning Protection, Surge Protection and Voltage Transient Protection | Dimension (L X W X H)Ø 110 × 100.8 mm (Ø 4.3" × 4.0") |
| What's in the Box (I51DN) | |
| ➀ 1X/4X Security Camera(s)➁ 1X/4X Mounting Screw Bag(s)➂ 1X User Manual➃1X Screw Driver (For dome camera only) | |
| I51DN Camera | |
| Image Sensor1/3" Progressive Scan CMOS | IVideo compressionH.265+/H.265/H.264+/H.264 |
| Main Stream Max. Frame Rate50Hz: 20 fps (2592 × 1944), 25 fps (2560 × 1440, 2304 × 1296, 1920 × 1080, 1280 × 720) | Sub-stream Max. Frame Rate50Hz: 25 fps (640 × 480, 640 × 360, 320 × 240) |
| 60Hz: 20 fps (2592 × 1944), 30 fps (2560 × 1440, 2304 × 1296, 1920 × 1080, 1280 × 720) | 60Hz: 30 fps (640 × 480, 640 × 360, 320 × 240) |
| Video Bitrate32 Kbps - 8 Mbps | Audio CompressionG.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC |
| Audio inputBulit-in Microphone | Lens2.8 mm |
| Min. IlluminationColor: 0.028 Lux @(F2.0, AGC On) | Angle of ViewHorizontal FoV 71.5°, Vertical FoV 53°, Diagonal FoV 91° |
| Number of Infrared LEDs2 pcs | Night Vision DistanceUp to 100 ft/30 m |
| Wide Dynamic Range120DB WDR | DNR3D DNR |
| ONVIFSupport | IR Cut FilterYes |
| EthernetRJ45 X1 (10 M/100 M) | |
| I51DN General | |
| HousingMetal & Plastic | ColorWhite |
| StorageBuilt-in microSD/SDHC/SDXC Slot, up to 256 GB | Hardware ResetYes |
| Operating PowerDC 12 V; PoE (802.3af) | Operating Temperature-22 °F – 140 °F/-30 °C – 60 °C |
| Indoor/Outdoor UseIndoor/Outdoor | Interface ProtectionIP67, TVS 2000 V Lightning Protection, Surge Protection and Voltage Transient Protection |
| Dimension (L X W X H)Ø120 × 92.2 mm (4.72" × 3.63") | Weight440 g (1.0 lb.) |
| Video & Audio (NVR) | |
| Video CompressionH.264+/H.264/H.265/H.265+/MPEG4 | IP Video Input8CH PoE |
| Video OutputHDMI up to 4K; VGA up to 1080p | Audio Input/Output1/1 RCA |
| Incoming Bandwidth80 M | Max Recording ResolutionUp to 8MP (3840 X 2160) |
| Max Playback ResolutionUp to 8MP (3840 X 2160) | Max Playback Channel8CH |
| Max Playback Capacity4CH @1080p; 1CH @8MP | |
| Hard Drive (NVR) | |
| HDD1 SATA Interface | HDD CapacityUp to 6 TB Capacity for Each HDD |
| External Interface (NVR) | |
| Network InterfaceRJ45 X1 (10/100/1000 M) | PoE8 Ports (IEEE802.3at / af) |
| USB2X USB 2.0 | |
| NVR General | |
| Operating PowerDC 48 V | Working Temperature14 °F — 131 °F/-10 °C — +55 °C |
| Dimensions (W X H X D)12.4” X 9.4” X 1.9”/315 X 240 X 48 mm | Weight (Without Hard Disk)2.2 lbs./1 kg |
| Power Consumption≤10 W (Without HDD and PoE) | |
| PoE: Max 25.5 W for Single Port | |
